Powder Vibratory Feeder Vertical Conveyor Elevator

Over the years, we have been adhering to the business philosophy of 'customer first, forge ahead' to provide high-quality products and services to new and old customers, scientifically integrate resources, strengthen corporate management and enhance corporate core competitiveness. Our high-quality Sulfonation equipment, sulphuric acid manufacturing plant, Low Density Hand Detergent Powder and outstanding services have been recognized by the majority of users. Customer satisfaction is our pursuit. 'Quality, integrity, efficiency, and service' are our constant goals. We are willing to sincerely cooperate with friends from all walks of life to create a better future! We strive to become a brand with first-class management, excellent quality and honest service. Our company will return to all new and old users for their continuous care and support with reliable products, reasonable prices, and good service.

   Detergent powder Plant by agglomeration process

Solid raw materials in form of powder are sieved and premixed, then stored in respective silos. The solid materials are weighed accurately by dosing belts according to the detergent powder formulation, and fed to the granulator. While the liquid raw materials are dosed accurately by dosing pumps and go into the granulator in form of sprayed particles. The agglomeration product from its bottom is fed to a fluidizing bed to remove free water in the particle’s surface and form crystal water in the powder to increase its added value. Perfume, enzyme and other minor ingredients are added into this powder in post-addition unit, then to be packed.

Central control room with computers

·The whole plant is automatically controlled by PLC

·The startup and shutdown of the plant is controlled by programs in the computers.

·There are interlocks between critical items of equipment, and monitoring of operation data.

·The functions of the system include detergent powder formulation adjustment; report printout, operation data display and recording/filing.

·Big screen showing how the plant is running. There are also alarmings and operator intervene indications.

·Manual and automatic operation modes can be switched between each other by operator.

·All raw materials, both solid and liquid, are automatically dosed according to detergent powder formulation by computer.

Post-Addition Unit

Base powder and minor solid ingredients, such as enzyme, and sodium perborate, etc., are dosed by electronic dosing belts or vibration feeders, then fed into a post-addition rotating mixer. While the liquid ingredients, such as nonionic and perfume are fed into the mixer by dosing pumps and sprayed inside the mixer. The powders and liquids are adsorbed/mixed together, yielding a stably formulated and homogenized medium/high-grade product detergent powder waiting to be packed.

30% of materials in the product powder can be added by this post-addition unit.

detergent powder plant Product brief description and advantages

1.We can offer all kinds of detergent powder production plant according to your special formulation and density .

2.Specialized in manufacturing detergent powder plant, it can be satisfied with all kinds of clients.

Custom properties

1.Technique   environment protection

Commission  professional service

design installation   professional service

2. capacity   3000t to 200000t/y

Technique   automatic

Technique   low consumption      Technique   environment protection

The operation mode can be manually and computer controlled.

The supply range is from renovation of existing plant to totally new plants.

Environmental impact: no wastewater is drained to outside.

If you're satisfied with our detergent powder plant assembling form plant, welcome to wholesale the high quality products with competitive price from us. As one of the leading manufacturers and suppliers in this profession, we can assure you of its reliable performance.

With experienced and skilled staff in the area of Powder Vibratory Feeder Vertical Conveyor Elevator, we continue to innovate our product portfolio and provide products to our customers. We always adhere to the tenet of 'today's quality, tomorrow's market', constantly meet the needs of the society and actively explore the international market. The company has been committed to the industry for many years, and has effectively promoted joint ventures and cooperation with major enterprises and manufacturers.
